Plastic Pipe Recycling Equipment

Horizontal Pipe Shredder for HDPE & PVC Pipes

Q: What is the maximum pipe size?

The maximum pipe diameter is 2,000 mm and the maximum pipe length is 6,000 mm, depending on the selected configuration. Provide both dimensions and the wall thickness so the machine can be sized for your material.

Q: What throughput can I expect?

The throughput range is 500–2,000 kg/hr. Actual output depends on pipe material, wall thickness, feeding conditions and machine configuration.

Q: Can smaller pipes be loaded inside larger pipes?

Yes. Smaller pipes can be nested inside larger pipes and fed together to make use of the hollow space. Keep the total load within the selected machine’s feeding capacity and use compatible materials if the shredded output will be recycled together.

Q: Do pipes need to be cut before shredding?

Pipe lengths up to 6,000 mm can be fed horizontally without cutting them into short sections, provided they fit the selected configuration. Longer pipes must be cut to fit.

Shred long, large-diameter HDPE, PVC and other plastic pipes at 500–2,000 kg/hr. Handles pipes up to 2,000 mm in diameter and 6,000 mm in length, with horizontal hydraulic feeding.

Process pipe lengths up to 6 m without cutting them into short sections.
Nest smaller pipes inside larger pipes and feed them together.
Match the machine to your pipe material, wall thickness and required output.

Get a Pipe Shredder Quote View Specifications

Built for Long & Large-Diameter Plastic Pipes

Nested Pipe Feeding

Load smaller pipes inside larger pipes to use the hollow space and process multiple pipe sizes in one feed.
Up to 6 m Pipe Length

Feed long pipe sections horizontally, reducing the need to cut them into short pieces before shredding.
Up to 2,000 mm Diameter

Handle large-diameter pipe scrap with a machine sized for the largest pipe in your feedstock.
Hydraulic Horizontal Feed

A hydraulic pusher advances the pipes toward the cutting rotor, reducing repeated manual repositioning.

Specifications

Parameter	Specification
Throughput	500–2,000 kg/hr
Maximum Pipe Diameter	2,000 mm
Maximum Pipe Length	6,000 mm
Pipe Materials	HDPE, PVC and other plastic pipes
Feeding System	Horizontal hydraulic pusher
Nested Pipe Feeding	Smaller pipes inside larger pipes

Swipe horizontally to view the full table.

Pipe Shredder

Throughput500–2,000 kg/hr

Maximum Pipe Diameter2,000 mm

Maximum Pipe Length6,000 mm

Pipe MaterialsHDPE, PVC and other plastic pipes

Feeding SystemHorizontal hydraulic pusher

Nested Pipe FeedingSmaller pipes inside larger pipes

Capacity and pipe size limits depend on the selected configuration; throughput varies with material, wall thickness and feeding conditions.

Watch the Horizontal Pipe Shredder in Action

Applications: HDPE, PVC & Other Plastic Pipes

HDPE Pipes

Pressure pipes, drainage pipes and thick-wall HDPE pipe offcuts from pipe production and recycling.
PVC Pipes

Rigid PVC water and drainage pipes, rejected pipe lengths and production offcuts.
Other Plastic Pipes

PP, PPR and other plastic pipe scrap. Specify the polymer and wall thickness when requesting a machine configuration.

Need High-Speed Pipe Chipping Instead?

For regular PE and HDPE pipes, our Pipe Chipper uses continuous side feeding and high-speed rotary cutting to produce coarse chips and strips. This Horizontal Pipe Shredder uses hydraulic push feeding for long pipe sections.

Equipment & Material Showcase

Pipe Shredder FAQ

What is the maximum pipe size?

What throughput can I expect?

Can smaller pipes be loaded inside larger pipes?

Do pipes need to be cut before shredding?

Warranty & Installation

Warranty Coverage

Standard warranty coverage is available for supported machine components and manufacturing defects.
Installation & Support

We provide installation guidance, commissioning support, operator training, and spare parts service according to project scope.

Get a Quote for Your Pipe Shredder

Send your pipe material, maximum diameter, length, wall thickness and required kg/hr, plus photos of the pipes. Let us know if you plan to feed smaller pipes inside larger ones.
